EIFS Mesh
Product Description
EIFS mesh is based on glass fiber woven fabric and is coated with polymer anti-emulsion soaking. It has good alkali resistance, flexibility, and high tensile strength in the warp and weft directions, and can be widely used for heat preservation, waterproofing, fireproofing, and cracking resistance of internal and external walls of buildings. The fiberglass mesh cloth is mainly alkali-resistant glass fiber mesh cloth, which is made of medium-alkali-free fiberglass yarn (the main component is silicate, which has good chemical stability) and is woven by a special structure-leno structure. Afterwards, It is subjected to high temperature heat setting treatments such as anti-alkali liquid and intensifiers.
Product information
Specification | Density mesh | Fabric mass (g/m) | Tensile strength N/5cm* 20cm | Fabric weave | Glue content (%) | Yarn | Woven roving | Horizontal | Vertical |
CNP50-5×5(4×4) | 5 | 5 | 50 | ≥650 | Leno | 12 | |||
CNP60 | 20 | 10 | 60 | ≥750 | Leno | 12 | |||
CNP65-5×5 | 5 | 5 | 65 | ≥660 | ≥660 | Leno | 18 | ||
CNP75-5×5 | 5 | 5 | 70 | ≥750 | ≥700 | Leno | 18 | ||
CNP75-4×4 | 4 | 4 | 70 | ≥400 | ≥1050 | Leno | 18 | ||
CNP80-5×5 | 5 | 5 | 80 | ≥750 | ≥850 | Leno | 18 | ||
CNP125-4×3.5 | 4 | 3.5 | 125 | ≥1050 | ≥900 | Leno | 18 | ||
CNP125-5×5 | 5 | 5 | 125 | ≥1180 | ≥1180 | Leno | 18 | ||
CNP145-5×5 | 5 | 5 | 145 | ≥1300 | ≥1650 | Leno | 18 | ||
CNP145-4×4 | 4 | 4 | 145 | ≥1000 | ≥1300 | Leno | 18 | ||
CNP160-5×5 | 5 | 5 | 160 | ≥1200 | ≥1200 | Leno | 18 | ||
CNP160-4×4 | 4 | 4 | 160 | ≥1200 | ≥1300 | Leno | 18 | ||
CNP180-4×3.5 | 4 | 3.5 | 180 | ≥1250 | ≥1500 | Leno | 18 | ||
CNP125-10×10 | 2.5 | 2.5 | 125 | ≥2000 | ≥2000 | Leno | 18 |
Product Features
1.EIFS mesh has good chemical stability. Alkali resistance, acid resistance, water resistance, cement erosion resistance, and other chemical corrosion resistance; strong adhesion to resin, soluble in styrene, etc.
2. High strength, high modulus and light weight.
3. Good dimensional stability, stiff, smooth, not easy to shrink and deform, and good positioning.
4. Good toughness. Good impact resistance.
5. Anti-mildew and insect-proof.
6. Fire prevention, heat preservation, sound insulation and insulation.
Product Application
1) On wall reinforcement materials (such as fiberglass wall mesh, GRC wallboard, EPS internal and external wall insulation board, gypsum board, etc.).
Packaging
1.Shrinkble film inside,strong plastic bag outside.
2.Shrinkble film inside,woven bag outside.
3.Carton box,2rolls in one carton or 4rolls in one carton.
4.30rolls in one carton with pallet.
Loading capacity;
In a 40 feet container we can load 105.000 sqm product with pallet and 145.000 sqm product without pallet.
Delivery Details
Within 5 working days for 1*40HQ.
Our Service
1.Free sample
We can send free samples for customer.If you need,pls contact me
2.Payment:
Pay 30% T/T as desposit,pay rest 70% against the copy of BL
L/C
Pay 30% T/T as desposit,pay rest 70% within 90days after the ship date
If you need EIFS mesh ,please free feel to contact us!
